CH₄ + C₂H₆

Target gases

Open-path TDLAS

Detection technology

ppb range

Detection resolution

GPS + Anemometer

Integrated components

Discover AMLD®

Vehicle-Mounted Methane & Ethane Detection

Discover AMLD® uses open-path TDLAS technology to detect methane and ethane during vehicle-based natural gas leak surveys. Designed for easy installation with minimal vehicle modifications, it combines gas detection with GPS and wind measurement to support pipeline leak inspection.

Discover AMLD.jpg

In partnership with Heath Consultants Inc.

Built for Vehicle-Based Gas Surveys

Discover AMLD enables vehicle-mounted detection of methane and ethane during natural gas leak surveys. Its open-path TDLAS technology, combined with GPS and wind measurement, helps survey teams detect potential leaks and distinguish pipeline gas from naturally occurring biogas.

Methane & Ethane Detection

Detect methane and ethane at parts-per-billion (ppb) range resolution to support natural gas leak surveys.

GPS & Wind Integration

Connect gas detection with GPS and anemometer data through the system’s proprietary tablet software.

Gas Source Differentiation

Use ethane measurements to help distinguish pipeline gas from naturally occurring biogas.

Easy Vehicle Installation

Install and remove the system with minimal modifications to the survey vehicle.

See the Product in Action

Technical Specifications

Specification
Details
Robotic Platform
Autonomous robotic dog
Methane Sensor Technology
SensorX FluX Multi
Detection Precision
Sub-100 ppb
Visual Sensing
Integrated visual sensors
Navigation
Can be trained to navigate inspection routes autonomously
Data Collection
SensorX X-Act App or UGCS software
GPS
GNSS-INS system at 10 Hz; <1 m accuracy
Response Time
Sample frequency of 100 Hz; data update rate of 10 Hz
Accuracy
±10% of reading for methane/ethane in natural gas; ±50% for quantification
Battery Life
8–10 hours

What's Included

Discover AMLD comes with the core detection instruments, vehicle mounting hardware, GPS equipment and software interface required for vehicle-based gas leak surveys.

01

Optics engine

03

Rooftop sensor and RF antenna

05

Tablet with proprietary software

07

Vehicle mounting hardware

02

Rotating target

04

GPS and anemometer

06

Battery packs and charger

08

Installation tools and accessories

Frame 1410103196.png

Product Brochure

Download the brochure to explore the product, features, specifications and applications.
